0.19mm Thickness BA R Electrolytic Tinplate for Food Packaging Tahini halve
Product Details
| Product Name:: | 0.19mm Thickness BA R Electrolytic Tinplate For Food Packaging Tahini Halve | Tin Coating:: | 1.1/1.1,2.0/2.0,2.8/2.8,5.6/5.6, Etc. Or Customerized |
|---|---|---|---|
| Surface Finish:: | B(Bright) R(Stone) S(Silver) | Use:: | Food Cans, Beverage Cans, Aerosol Cans, Cosmetics, Paint Cans, Chemicals Cans, Storage Cans, Battery,stationery, Etc |
| Thickness:: | 0.15-0.50mm | Package:: | Thin Plastic Film + Rust-proof Paper+metal Cover+metal Angles+straps+pallets |
| Standard:: | JIS DIN ASTM GB EN AISI | Hardness:: | T1-T5,DR9,DR8 |
| Highlight |
tinplate food packaging 0.19mm,electrolytic tin plate 865mm,TFS tinplate 940mm |
||
Product Description
Tinplate, thin steel sheet with a coating of tin applied either by dipping in molten metal or by electrolytic deposition; almost all tinplate is now produced by the latter process. Tinplate made by this process is essentially a sandwich in which the central core is strip steel.
Recyclable: The iron can itself has a characteristic that other packaging materials do not have - can be adsorbed by magnets, so that the iron can can be separated from the waste by magnetic force by magnetic separator, using this characteristic can easily achieve the effect of recycling 80% of the iron can in waste. The invention of environmental protection cover not only makes the use of iron cans safer and healthier, but also effectively reduces the amount of garbage, and has direct and obvious benefits for recycling operations.
| Specification | |
| Thickness: 0.15mm – 0.50mm | Width: 700mm -1050mm |
| Anneal: CA/BA | Material: MR/SPCC |
| Temper | |
| Single Reduced: T1,T2,T2.5,T3,T4,T5 | Double Reduced: DR8, DR9, DR10 |
| Surface Finish: Bright, Stone, Silver, Matte | |
| Tin-coating: | |
| Equal Tin-coating: 1.1/1.1, 2.0/2.0, 2.8/2.8, 5.6/5.6,8.4/8.4,11.2/11.2 | Differential Tin-coating: 2.0/1.1, 2.8/1.1, 2.8/2.0,5.6/1.1,5.6/2.0,5.6/2.8,etc |
| Temper | ||||
| Standard | Japanese Standard | Chinese Standard | European Standard | American Standard |
| JIS3303-2002 | GB/T 2520-2000 | DIN EN 10203-1991 | ASTM623M-2002 | |
|
Single-Reduced
|
T1 | TH50+SE | TS230 | T1(T49) |
| T2 | TH52+SE | TS245 | T2(T53) | |
| T2.5 | TH55+SE | TS260 | T2.5(T55) | |
| T3 | TH57+SE | TS275 | T3(T57) | |
| T4 | TH61+SE | TH415 | T4(T61) | |
| T5 | TH65+SE | TH435 | T5(T65) | |
|
Double-Reduced
|
DR7 | H71+SE | TH520 | DR7(T71) |
| DR8 | H73+SE | TH550 | DR8(T73) | |
| DR9 | H76+SE | TH620 | DR9(T76) | |
| Surface Finish | ||
| Classification | Symbol | Specific feature |
| Bright Finish | B | A luster finish provided by a flow-melted tin coating on a smoothly finished steel based with grindstone-pattern. |
| Stone Finish | R | A luster finish provided by a flow-melted tin coating on a steel base characterized by a directional grindstone-pattern. |
| Silver Finish | S | A luster finish provided by a flow-melted tin coating on a coarse dull-finished steel base. |
| Matte Finish | M | A dull finish usually provided by an unflow-melted tin coating on a dull finished steel base. |
| Tin Coating | ||||
| Type | Former Coating Designation | Coating Weight Code | Nominal Coating Weight(g/m2) | Minimun Average Coating Weight(g/m2) |
| Equal tin-coating (E) | 10# | 1.1/1.1 | 1.1/1.1 | 0.9/0.9 |
| 20# | 2.0/2.0 | 2.0/2.0 | 1.8/1.8 | |
| 25# | 2.8/2.8 | 2.8/2.8 | 2.5/2.5 | |
| 50# | 5.6/5.6 | 5.6/5.6 | 5.2/5.2 | |
| 75# | 8.4/8.4 | 8.4/8.4 | 7.8/7.8 | |
| 100# | 11.2/11.2 | 11.2/11.2 | 10.1/10.1 | |
| Differential tin-coating (D or A) | 20#/10# | 2.0/1.1 | 2.0/1.1 | 1.8/0.9 |
| 25#/10# | 2.8/1.1 | 2.8/1.1 | 2.5/0.9 | |
| 50#/10# | 5.6/1.1 | 5.6/1.1 | 5.2/0.9 | |
| 50#/25# | 5.6/2.8 | 5.6/2.8 | 5.2/2.5 | |
| 75#/25# | 8.4/2.8 | 8.4/2.8 | 7.8/2.5 | |
| 75#/50# | 8.4/5.6 | 8.4/5.6 | 7.8/5.2 | |
| 100#/25# | 11.2/2.8 | 11.2/2.8 | 10.1/2.5 | |
| 100#/50# | 11.2/5.6 | 11.2/5.6 | 10.1/5.2 | |
| 100#/75# | 11.2/8.4 | 11.2/8.4 | 10.1/7.8 | |
